The Dexter-Lawson Series “A” Drill System

Dexter-Lawson’s high performance Series “A” Drill System is designed for the ultimate in productivity and price performance. Combining our industry-leading 76mm lift capacity with a fully adjustable backgauge. We thank you for taking the time to consider a Dexter-Lawson Drill for your needs, and hope we will have the opportunity to help your business. The information on this page is a basic overview of the capabilities and features of Dexter-Lawson’s Series “A” Drill. If you need more specific information, you can contact us to have one of our Service Managers speak to you directly about your company’s individual needs.

Dexter-Lawson Manufacturing – Series “A” Drills

At Dexter-Lawson we know that the least you can ask of your drill is to do the job, do it right, and keep doing it for a long time. That is why we have designed our Series “A” Drills for true heavy-duty operation. Each Series “A” Drill will meet the production requirements of the busiest plant, while performing trouble-free for years.

But doing only the least, has never been the Dexter-Lawson way. We could have stopped at having one of the most rugged and durable drills in the industry, but we believed our customers needed more.

We started by pricing our “A” Drill to give you the ultimate combination of price & performance. Of course, with performance, comes the need for safety — such as The Lawson Group’s ongoing Commitment to Safety, and Dexter-Lawson’s fully upgradeable safety features (ensuring that your Series “A” Drill System will always be at the forefront in product safety standards). Next, we combined our industry leading 76mm lift capacity with many standard features found only on larger more expensive drill systems.

Finally, we added our comprehensive product warranty, preventative maintenance, and field service programs to give you that extra peace of mind, knowing that Dexter-Lawson stands behind its products and will help you get the most from your “A” Series Drill (or any other D-L machinery that you have chosen for your plant).


  • Heavy Duty design

  • 76mm lift heights up to 10 heads

  • Variable drill stroke speeds

  • 381mm Back gauge depth

  • 711mm Drill width

  • 3 H.P. Easy set-up

  • Purchase includes 4 heads

  • Touch Screen Controls


  • Air cooling

  • Vacuum chip disposal
