Mod. S2 160 Hot Printing Machine

Rapid processing thanks to three head settings and very simple machine function make this System ideal for both large and small scale production. Electronic material stop; conveyor through printer with touch-key programming in millimeters or inches, complete with decimal correction. One programmable electronic feed foil step conveyor system, plus the possibility of foil advance of 90° angle in transverse or longitudinal direction in relation to the web to print, by means of foil- holder rotation.

The adjustable printing unit and die cutting unit can be set in longitudinal, sideways end I rotating directions. Printing and die cutting block: 160×140. Material passage with 160mm. Electronic speed variation: approx. 9000 cycles/hour according to printing size. Dual shaft rewinding with separate tension adjustment. The machine is equipped with, all the necessary CE stan­dard requirements.

Mod. S3 330

  • Weight 2800G

  • Height 1.650 mm

  • Length 2.000mm

  • Absorption 3KW

  • Width 1.000 mm

  • Hot printing and die-cutting surface 160 x 140 mm

  • Material passing width 160 mm

  • Cycles per hour 10.000 max (only die-cutting 10.000 max only printing 8.000 max)
